Acid Resistant Metal-Free Boron Carbide Sandblast Nozzle with Long Venturi 45x8mm for Ceramic Surface Treatment
Ürün ayrıntıları:
| Menşe yeri: | Hunan, Çin |
| Marka adı: | High Broad |
| Sertifika: | ISO 9001:2015 |
| Model numarası: | HB-B4C |
| Belge: | Venturi nozzle Jane.pdf |
Ödeme & teslimat koşulları:
| Min sipariş miktarı: | 10 adet |
|---|---|
| Fiyat: | USD 10.00 - 28.00 / Piece |
| Ambalaj bilgileri: | Bireysel köpük kaplı kutu, nem bariyerli ihracat sınıfı oluklu karton |
| Teslim süresi: | Stok için 3-5 iş günü, üretim için 15-20 gün |
| Ödeme koşulları: | T/T,L/C,PayPal,Western Union |
| Yetenek temini: | Aylık 50000 Adet |
|
Detay Bilgi |
|||
| Meme tipi: | Uzun Venturi Deliği | Bağlantı iş parçacığı: | M16x1.5 |
|---|---|---|---|
| Delik Çapı: | 8 mm | Meme Uzunluğu: | 45mm |
| Sertlik: | ≥2800 Düğme (HK) | Maksimum Çalışma Basıncı: | 0,8 MPa (116 PSI) |
| Vurgulamak: | Acid Alkali Resistant Nozzle,Zero Metal Contamination Design,Pure Ceramic Sandblast Tip |
||
Ürün Açıklaması
Key Advantages
Zero Metal Contamination
100% B4C ceramic body with no metallic components. Eliminates ferrous and non-ferrous contamination during blasting — critical for semiconductor, medical device, and aerospace component processing.
Acid and Alkali Resistant
Outstanding chemical inertness against acidic and alkaline environments. Performs reliably in wet blasting with chemical additives without material degradation.
Long Venturi Design
45mm extended venturi bore with 8mm diameter maximizes particle acceleration distance. Delivers superior blasting uniformity across large surface areas.
Ceramic Surface Ready
Optimized for ceramic, glass, quartz, and other brittle material surface treatments. Gentle yet effective abrasive flow preserves substrate integrity.
Technical Specifications
| Material | Boron Carbide (B4C) Ceramic |
| Nozzle Type | Long Venturi Bore |
| Bore Diameter | 8mm |
| Nozzle Length | 45mm |
| Metal Content | Zero (100% ceramic) |
| Chemical Resistance | Excellent acid/alkali resistance |
| Hardness | ≥2800 HK (Knoop) |
| Max Operating Pressure | 0.8 MPa (116 PSI) |
Applications
- Semiconductor wafer and component surface treatment
- Medical implant and surgical instrument finishing
- Ceramic and glass substrate etching and texturing
- Aerospace turbine blade coating preparation
- Precision optical component cleaning
