Silicon Carbide UHMWPE Hybrid Protection Plate NIJ III Plus 10x12 Inch SiC PE Composite Multi-Hit Armor Insert
Ürün ayrıntıları:
| Menşe yeri: | Hunan, Çin |
| Marka adı: | High Broad |
| Sertifika: | NIJ 0101.06 Level III+, ISO 9001:2015 |
| Model numarası: | HB-SIC-HYB-3P-1012 |
| Belge: | SIC Ballistic Armor Tiles-P...ad.pdf |
Ödeme & teslimat koşulları:
| Min sipariş miktarı: | 10 adet |
|---|---|
| Fiyat: | USD 20-75 / Piece |
| Ambalaj bilgileri: | Oluklu kutu, ihracat sınıfı kontrplak palet ile bireysel EPE köpük ambalajı |
| Teslim süresi: | Numuneler için 5-7 iş günü, toplu siparişler için 15-25 gün |
| Ödeme koşulları: | T/T, L/C, Western Union, PayPal |
| Yetenek temini: | Aylık 5000 Adet |
|
Detay Bilgi |
|||
| Malzeme: | Silisyum Karbür (SiC) + UHMWPE Kompozit | NIJ Koruma Seviyesi: | Seviye III+ (M80 NATO + M855 Yeşil Uç) |
|---|---|---|---|
| Boyutlar: | 10x12 inç (250x300 mm) | Kalınlık: | 10,5 mm (Toplam Kompozit) |
| Alan Yoğunluğu: | 24,8 kg/m² | Ağırlık: | 2,45 kg (Tek Plaka) |
| Sertlik (Vuruş Yüzü): | 2600 HV (Dökülme) | PE Destek Kalınlığı: | 6,5 mm |
| Seramik Katman Kalınlığı: | 4,0 mm | Çoklu Vuruş Yeteneği: | 6 Mermi M80 + 3 Mermi M855 |
| Eğri Türü: | Çok Kavisli SAPI Kesim | Raf ömrü: | 10 yıl |
| Çalışma Sıcaklığı: | -40°C ila +70°C | ||
| Vurgulamak: | Silicon Carbide UHMWPE armor plate,NIJ III Plus bulletproof plate,10x12 inch SiC PE composite |
||
Ürün Açıklaması
Silicon Carbide + UHMWPE Hybrid Protection Plate — The Ultimate Cost-Performance Formula
Why Hybrid Design Beats Pure Ceramic or Pure PE Every Time
| Armor Type | Weight (10x12) | NIJ Rating | M855 Stopped | Cost Index |
|---|---|---|---|---|
| SiC + UHMWPE Hybrid | 2.45 kg | III+ Special Threat | YES | 100% (baseline) |
| Alumina + PE Hybrid | 3.1 kg | III+ Special Threat | YES | 85% |
| Pure PE (UHMWPE Only) | 1.6 kg | III (M80 only) | NO | 110% |
| B₄C + PE Hybrid | 2.1 kg | III+ Special Threat | YES | 165% |
The HB-SIC-HYB-3P-1012 hybrid plate represents our optimized cost-performance design. By combining a 4.0mm SiC ceramic strike face with a 6.5mm UHMWPE composite backing, we achieve NIJ III+ special threat protection at a weight and price that neither pure ceramic nor pure PE can match.
- Alumina hybrid plates need thicker ceramic layers (6-7mm) to defeat M855, adding weight — our SiC hybrid is 21% lighter.
- Pure UHMWPE plates cannot stop M855 (SS109) penetrator rounds due to the steel tip piercing through the PE fibers — our SiC face shatters the penetrator on contact.
- Boron Carbide hybrids achieve similar performance but at a 65% cost premium — our SiC design gives you the same defeat capability at a fraction of the price.
Key Features
- NIJ III+ Special Threat Rated: Stops 7.62*51mm M80 NATO AND 5.56*45mm M855 (SS109) Green Tip penetrator rounds
- 4.0mm SiC Strike Face: Optimum thickness calculated for M855 steel penetrator defeat while minimizing weight
- 6.5mm UHMWPE Backing: Industry-standard High-grade PE laminate captures ceramic fragments and minimizes BFD
- Multi-Curve SAPI Cut: Anatomical fit for all-day wear comfort, compatible with standard SAPI/ESAPI plate carriers
- 6+3 Multi-Hit Proven: 6 rounds M80 plus 3 rounds M855 within the NIJ dispersion zone
Ideal For
- Protection units facing both 7.62mm and 5.56mm threats on the modern battlefield
- SWAT teams requiring M855/Green Tip defeat for urban operations
- Border patrol and counter-terrorism units needing multi-threat protection
Get the best cost-performance armor plate on the market. Contact our sales team for pricing, samples, and OEM branding options.
